TYPE | ITEM | MEASUREMENT | SP-880 Combined type | SP-880 Standard type |
END PRODUCT | Material | / | PET/PP/PE/PC | PET/PP/PE/PC |
Volume | L | 0.05-2.5(2-cavity) 3-6(1-cavity) | 0.05-2.5 (2-cavity) 3-6 (1-cavity) | |
Theoretical output | Pcs/h | 0.05-2.5L/1700 3-6L/800 | 0.05-2.5L/850 3-6L/400 | |
Max.length | mm | 360 | 360 | |
max.diameter | mm | 180 | 180 | |
MOULD PLATE | Max.mould plate | mm | 420×500 | 420×500 |
Max.mould thickness | mm | 160-240 | 160-240 | |
Clamping force | KN | 90 | 90 | |
Mould opening stroke (adjustable) | mm | 200 | 200 | |
AUXILARY | High pressure Compressor M3/Mpa | KW | >=0.70/3.0×1set 22 | >=0.7/3.0×2sets 22 |
Precision air filters | M3/Mpa | >=1.0/3.0×2pcs | >=1.0/3.0×2pcs | |
MAIN MACHINE ELECTRICITY | Power | KW | 12 | 12 |
Voltage/Frequency | V/HZ | 220-380/50-60 | ||
MACHINE SIZE | Main body dimension(L×W×H) | M | 1.45×0.6×1.75 | 1.45×0.6×1.75 |
Main body weight | T | 0.6 | 0.6 | |
Conveyor dimension(L*W*H) | M | 1.40×0.62×1.25 | 1.40×0.62×1.25 | |
Conveyor weight | T | 0.22 | 0.22 | |
SAFTY | Auto-emergency alarm | SAFETY INTER-LOCKING DEVICE | ||
